General Purpose Telescopic Cylinders

Characteristics:

Telescopic cylinders for general use

700 bar of working pressure

combining a short piston stroke with a short retracted height.

For use where there is a minimum clearance for the cylinder's introduction and a high lift is required.

Single acting and a load return.

High-quality alloy steel for long-lasting use.

Wear and corrosion are resistant to chrome-plated pistons.

For better corrosion resistance, baked enamel finish.

A dust cap and HH-II R2 3/8 male half coupler are included in each cylinder.

Flat-graining saddles are present in each cylinder.
