Products Description:
Characteristics:
700 bar of working pressure
Designed to be used in any position.
High-quality alloy steel for long-lasting use.
Wear and corrosion are resistant to chrome-plated pistons.
The piston rod's dust wiper helps to prevent contamination.
For better corrosion resistance, baked enamel finish.
Before leaving our factory, all cylinders are subject to a 125% capacity proof test.
Roller burnishing is used to smoothen and harden the surface of 10 to 100 ton cylinder bores.
The spring-return of the 10 to 200 ton cylinder models is the load-return of the 250 to 1000 cylinder models.
Flat-graining saddles are present in each cylinder.
On request, tilt saddles are available.
